Conbraco/Apollo 19-MHGA-150 | Bronze Safety Valve Brass Trim Metal Seat 1-1/2" NPT Section I Steam 150 PSI
Couldn't load pickup availability
Got questions? Ask an expert!
Overpressure protection of steam boilers, sterilizers, distillers, cookers, and pressure reducing stations. Pneumatic conveying equipment, air compressors, receivers and dryers. Steam, air and gas accumulators, pressure vessels and pressure piping systems.
Features
- New! Wider wrenching hex for easier, faster installations
- New! European Pressure Equipment Directive Compliant (optional)
- Max. temp. 406°F, 422°F with stainless steel trim
- 12 sizes, 1/2" thru 2-1/2" NPT
- Stainless steel spring
- Optional 316 stainless steel wetted trim (Specify 19L or 19S Series)
- Available in metal and soft seat designs
- Metal to metal seat lapped to optical flatness
- Less costly repairing, soft seat easily replaced
- Double ring, full bore, high-capacity design
- Registered in all Canadian provinces and territories CRN #0G8547.5C
- Options
- Choice of Teflon® or metal to metal seating
- Steam set pressures to 300 psi @ 422° F (Model 19S, stainless steel trim)
- 316 stainless steel wetted trim available for all sizes
- Anti-vibration dampened lifting lever
| Brand | Conbraco/Apollo |
|---|---|
| MPN | 19-MHGA-150 |
- SKU CON19-MHGA-150
