ASCO 83779 1/2" 3-Way Normally Closed Fuel Oil Solenoid Valve
Couldn't load pickup availability
Got questions? Ask an expert!
The ASCO 83779 is a 1/2-inch NPT, 3-way normally closed, direct-acting fuel oil solenoid valve engineered for the reliable control of fuel oil up to 1500 SSU. Constructed with a durable brass body and equipped with high-quality Viton seals and discs, this 120 VAC valve features an "Inlet Position B" configuration and operates effectively across a 0 to 100 PSI pressure range. Housed in a standard NEMA 1 enclosure, it ensures secure and consistent flow management for demanding commercial and industrial applications.
- Manufacturer: ASCO
- Part Number: 83779
- Product Type: Fuel Oil Solenoid Valve
- Valve Design: 3-Way, Normally Closed (Direct Acting)
- Pipe Size: 1/2" NPT
- Body Material: Brass
- Internal Components: Viton seal and disc
- Electrical Specifications: 120 VAC
- Flow Capacity (Cv): 1.0
- Pressure Rating: 0 to 100 PSI
- Compatible Media: Fuel oil (up to 1500 SSU)
- Inlet Position: B
- Enclosure Rating: NEMA 1
- SKU ASCO83779
