ASCO 8262G202V | 1/4" 2-Way Normally Closed Brass Solenoid Valve (120V)
Couldn't load pickup availability
Got questions? Ask an expert!
The ASCO 8262G202V is a versatile 1/4-inch female threaded, 2-way normally closed solenoid valve engineered for reliable, high-flow plumbing applications. Constructed with a durable brass body and featuring a proven small poppet valve design, it ensures an exceptionally tight shutoff. This 120V unit can be conveniently mounted in any position and comes equipped with a standard watertight NEMA 4X enclosure, making it a highly dependable choice for managing water, air, inert gases, and light oils across a variety of service conditions.
Specifications
| Brand | ASCO |
|---|---|
| MPN | 8262G202V |
| Product type | Solenoid Valve |
| Valve design | 2-Way, Normally Closed (Small poppet for tight shutoff) |
| Pipe size | 1/4" Female Threaded |
| Body material | Brass |
| Electrical specifications | 120V (10.1 Watts AC / 11.6 Watts DC) |
| Flow capacity (Cv) | 0.5 (High Flow) |
| Maximum AC pressure rating | 200 PSI (Water) / 180 PSI (Air-Inert Gas) / 145 PSI (Light Oil @ 300 SSU) |
| Maximum DC pressure rating | 40 PSI (Water) / 40 PSI (Air-Inert Gas) / 45 PSI (Light Oil @ 300 SSU) |
| Maximum fluid temperature | 180°F (AC) / 150°F (DC) |
| Ambient temperature range | 32°F to 125°F (AC) / 32°F to 104°F (DC) |
| Enclosure type | Standard Watertight (NEMA Types 1, 2, 3, 3S, 4, and 4X) |
| Installation | Multi-poise design allows for mounting in any position |
- SKU ASCO8262G202V
