Siemens 42BF35AG | Class 42 Non-Reversing Definite Purpose Contactor, 240V Coil, 30 a, 4NC-4NO Contact, 3 Poles
Regular price
$79.00
Couldn't load pickup availability
100% Secure Payments
Industry Leading Quality & Service
Got questions? Ask an expert!
Features
- 10 hp at 460/480 V, 15 hp at 575/600 V
- 10 A at 600 VAC, 11 A 1/2 hp at 125 to 250 VAC, 0.6 A at 125 VDC, 0.3 A at 250 VDC contact rating of auxiliary contacts
Specifications
| Brand | Siemens |
|---|---|
| MPN | 42BF35AG |
| Frequency rating | 50/60 Hz |
| Maximum load current | 30 A |
| Mounting type | Surface |
| Number of auxiliary contacts | 4 |
| Number of poles | 3 |
| Operating cycles | 250000 cycles |
| Operating temperature | 158 deg F |
| Minimum order qty | 1 |
| Order interval | 1 |
| Coil voltage | 240 V |
| Contact type | Auxiliary |
| Terminal type | Screw |
| Standards and approvals | ARI 780/790, cULus Recognized, ECCN:EAR99, UL File No. E14900, REACH Article 33 |
| Type | Class 42 Non-Reversing |
| Dimensions | 3.69 in H x 2.38 in W x 2.87 in D |
| Contact rating | 10 A, 11 A 1/2 hp, 0.6 A, 0.3 A |
| Contact configuration | 4NC-4NO |
| Coil power rating | 10 hp, 15 hp |
- SKU SIEMAN42BF35AG
