ASCO 8030G83 | 3/4" NPT 2-Way Normally Open Brass Solenoid Valve (120V)
Couldn't load pickup availability
Got questions? Ask an expert!
The ASCO 8030G83 is a versatile, general-purpose 3/4-inch NPT 2-way normally open solenoid valve engineered for reliable low-pressure control of air, inert gas, and water. Constructed with a durable brass body and equipped with high-quality NBR seals within a rugged NEMA 4X enclosure, this 120 VAC valve ensures secure and consistent operation even in demanding environments. Featuring a 3/4-inch orifice and a 5.5 Cv flow factor, it operates efficiently at low pressures requiring only 0 to 2 PSI.
Specifications
| Brand | ASCO |
|---|---|
| MPN | 8030G83 |
| Product type | General Purpose Low Pressure Solenoid Valve |
| Valve design | 2-Way, Normally Open |
| Pipe size | 3/4" NPT |
| Orifice size | 3/4" |
| Body material | Brass |
| Internal components | NBR seals |
| Electrical specifications | 120 VAC |
| Flow capacity (Cv) | 5.5 |
| Heating capacity | 295,000 BTU |
| Operating pressure | 0 to 2 PSI (for air, inert gas, and water on AC power) |
| Maximum fluid temperature | 180°F (AC power) |
| Enclosure rating | NEMA 4X |
| Compatible media | Air, inert gas, and water |
- SKU ASCO8030G83
